Simple Pallet (GS-JAQ2106)

  • 1
  • 2
  • 3

Brand Name : GS

Model Number : GS-JAQ2106

Place of Origin : China

MOQ : 1 PCS

Price : USD+negotiable+pcs

Payment Terms : T/T

Supply Ability : 1+pcs+per days

Delivery Time : 1-7 days

Packaging Details : 900*650*150mm

Model : GS-JAQ2106

Overall dimensions (length * width * height) : L(800mm)*W(410mm)* H(102mm)[Please refer to the following illustration]

Weight : 17KG

Working voltage : Dc 24V

Gas source requirements : no

Maximum power : 20W

Cutting speed : 5S

Drive mode : Electric

Operation panel : Button operation

Communication method : no

Applicable pallet size : L(170-230mm) W(max:340mm) H(max:27mm)[Please refer to the following illustration]

Condition : New

Contact Now

Simple Pallet (GS-JAQ2106)

The simple tray is an automated device that supplies electronic components by switching material trays back and forth, and it can achieve continuous feeding without stopping the machine.

Simple Pallet (GS-JAQ2106)

Simple Pallet (GS-JAQ2106)

Simple Pallet (GS-JAQ2106)

Simple Pallet (GS-JAQ2106)


If there are special material dimensions, you can contact our company for consultation and to provide solutions and customize exclusive feeders.
