Tape Adjustment Feeder(GS-RAZ2211)

Brand Name : GS

Model Number : GS-RAZ2211

Place of Origin : China

MOQ : 1 PCS

Price : USD+negotiable+pcs

Payment Terms : T/T

Supply Ability : 1+pcs+per days

Delivery Time : 1-7 days

Packaging Details : 900*650*120

Model : GS-RAZ2211

Weight : 17KG

Working voltage : Ac 220V

Gas source requirements : 0.5MPa

Maximum power : 400W(Direct vibration: 330W)

Feeding speed : 1.5s/Pcs

Drive mode : Electric[Blow air to assist in throwing the waste tape]

Operation panel : 0.96-inch TFT color screen 80*160 pixels

Error in the length of the material cutting feet : ±0.1mm

Applicable to the hole spacing of the tape : 12.7mm/15mm[ Parts need to be replaced]

Applicable material body height : ≤47mm

Applicable material pin diameter : ≤0.8mm

Pin span : ≤30mm

Function of cutting waste tape : By default, there is[By default, there is none. Circular materials cannot be bent]

The number of times the cutter is used : One million

Condition : New

Contact Now

Tape adjustment feeder(GS-RAZ2211)

The vertical feeder is an electronic component supply device that keeps a certain interval and sends out the electronic components of the vertical tape packaging one by one at a specified time, cuts the lead wires, and supplies them to the insertion machine.

Tape Adjustment Feeder(GS-RAZ2211)

Tape Adjustment Feeder(GS-RAZ2211)

Tape Adjustment Feeder(GS-RAZ2211)

If there are special material dimensions, you can contact our company for consultation and to provide solutions and customize exclusive feeders.
